F3.8X.H.XX
Oval Gear Flow Sensors
Oval Gear Flow Sensors
FLS Oval Gear Flow
sensors F3.80 have been
designed following the
main industrial application
requirements: high mechanical
resistance and reliable
performances.These sensors
are suitable to measure a wide
range of viscous solid-free
liquids with a very high accuracy
and repeatability.
The sensors can be fixed
to flexible or rigid pipes via
1/4” GAS threaded process
connections. The construction
materials, ECTFE (Halar®) or
PP or Stainless steel, provide
high strength and chemical
resistance.
| Indeks | - | Wymiar | Kategoria produktu | System | product.detail.attribute.Version | Napięcie | Długość sensora |
Materiał | product.detail.attribute.Enclosure | product.detail.attribute.Flow Rate Range | Masa gr/szt. |
|---|---|---|---|---|---|---|---|---|---|---|---|
| F3.81.H.01 | - | - | Automatyka | Automatyka | Hall | 5 - 24 VCC | 54 mm | PP $ ECTFE $ FKM | IP65 | From 10 to 100 l/h* | 200 |
| F3.81.H.02 | - | - | Automatyka | Automatyka | Hall | 5 - 24 VCC | 54 mm | ECTFE $ ECTFE $ FKM | IP65 | From 10 to 100 l/h* | 300 |
| F3.81.H.03 | - | - | Automatyka | Automatyka | Hall | 5 - 24 VCC | 54 mm | 316L SS $ FKM | IP65 | From 10 to 100 l/h* | 800 |
| F3.82.H.01 | - | - | Automatyka | Automatyka | Hall | 5 - 24 VCC | 54 mm | PP $ ECTFE $ FKM | IP65 | From 10 to 100 l/h* | 200 |
| F3.82.H.02 | - | - | Automatyka | Automatyka | Hall | 5 - 24 VCC | 54 mm | ECTFE $ ECTFE $ FKM | IP65 | From 10 to 100 l/h* | 300 |
| F3.82.H.03 | - | - | Automatyka | Automatyka | Hall | 5 - 24 VCC | 54 mm | 316L SS $ FKM | IP65 | From 10 to 100 l/h* | 800 |
- APPLICATIONS • Chemical industry • Laboratory plants • Dosing systems • Pulsating flows measurement • High viscosity and not conductive fluid measurement • Oil measurement MAIN FEATURES • Compact dimensions • Easy installation • High chemical resistance • High viscosity fluids measurement • Low pressure loss
